Products Home >> Products
CP4040-150-G13



Engine modelCP4040-150-G13
Inlet/outlet at size [ in ]4X3
Displacement Q.max[m3/h]80
Lift H.max[m(ft)]60
Suction[m]7
Speed[rpm]3600
Engine modelAir-cooled,single,4-stroke
Rated power[KW(Hp)]13
Displacement[ml]389
Starting systemRecoil and hand-operated
Fuel tank capacity[L(gal.]6.5
Continuous working time[h]8
Overall dimension(LxWxH)[mm]625X475X535
Dry weight[kg]62
