名称Model

GTF3030-208-10

水泵尺寸Inlet/outlet at size [ in ]

3x3-208-10

最大流量Displacement Q.max[m3/h]

76.5

最大扬程Lift H.max[m]

95

最大吸程Suction[m(ft)]

7

转速Speed[rpm]

3600

动力Rated power[KW(Hp)]

hongda 690

动力额定功率Rated power[HP]

25

排量Displacement[ml]

690

启动方式Starting system

手动或电启动/Recoil and hand-operated

油箱容积Fuel tank capacity[L]

6.5

持续工作时间Continuous working time[h]

8

外形尺寸Overall dimension(LxWxH)[mm]

660X580X680

重量Dry weight[kg]

82
